The main features
Ultra-low stray light: the first time in five ten thousandths of stray light indicators on the economy UV-Vis spectrophotometer.



Excellent stability: excellent selection, stable and durable.

◇ Advanced Stepping Motor Drive Technology
    Grating motor direct drive, replace the conventional screw drive mechanism, and transmission do not need to do regular maintenance to ensure that the instrument for a long time maintenance-free work.
◇ Full sealed monochromator structure
    Sealed structure and optical mirror surfaces are coated with a SiO2 film, double protection to ensure the instrument's optical parts from the gas and the environment.
◇ carefully selected light source
    Tungsten lamp, deuterium lamp selection of world-renowned brands, to ensure the light of long-term stable and reliable.
The ◇ machine the whole mold production
    Various components used in all the anti-corrosion material, greatly improving the instrument weather resistance.


Flexible scalability: hardware to facilitate the demolition, the flexibility to upgrade software.

◇ rich extensions
    T60 series has a dedicated function slot, by inserting a different function card pesticide residue measurement, and function of DNA / protein measurements and a full band scan cards to meet the different needs of various user
◇ open application platform
    T60 series to open the sample compartment design, easy application and experimentation of a variety of accessories.
◇ powerful application software
    Through the communication interface connected to the computer, using powerful software accessories can greatly extend the stand-alone function, the measurement of high-grade UV instruments and data processing functions.
◇ variety of output forms
    With the printer linked to the support of micro-printer, the HP series inkjet, laser printers, user-friendly to use.
◇ convenient online upgrade system

    The user can at any time via the Internet to download the latest program of the instrument, the instrument upgrade.




The overall design of humanity: a high degree of automation and easy maintenance.

And ◇ fast scanning speed
    Wavelength shift speed up 7000nm/min wavelength scanning speed of up to 2500nm/min greatly improve user productivity.
The ◇ automatic operation
    T6 products with automatic wavelength positioning, wrapping lights, Automatic wavelength calibration, and automatic sample cell switching function.
◇ Built-in storage racks cuvette
    Set cell holder on one side of the sample chamber, the use of user-friendly.
To ◇ automatic lamp life detection system
    Automatic lamp life detection system, to ensure the reliability of the instrument work.
◇ easily washable dust filter
    Using washable dust filter designed to ensure the internal cleaning of instruments, ease of maintenance.
◇ easy disassembly
    Instruments at the bottom of the locking mechanism and the knob behind the institutions, expansion and maintenance of user-friendly.








Powerful and convenient software analysis assistant - UVWin5 .0

The ◇ four conventional measurement capabilities
   Photometry, quantitative determination, spectral scanning, time scanning
◇ innovative three-dimensional spectrum function
   Can realize the multi-spectral combination are displayed as three-dimensional spectra;
   Three-dimensional spectrum of light, colored, layered effects processing;
   Peak detection function;
   Can spectra Print.
◇ customized measurement package for all walks of life
   Genetic analysis-DNA protein measurement package
   Drug analysis - national pharmacopoeia package
   Food Analysis - Food Analysis Software Package
   Environmental Analysis - Environmental Analysis Software Package
   Pesticide - A pesticide residues Packages
◇ software to follow GLP guidelines
   Multi-User Management: Allows administrators to create users and groups with different permissions; each user login software need to enter the appropriate username and password; measurement data for the average user
   Logging function: automatically record the user's operation; log files are more reliable database format; administrator can log classification of access and other treatments.
   Binary file to save: to save measurement data format uses a binary format; binary format greatly enhance the level of confidentiality of data; also saves disk space.
   Quality control functions: to monitor the measurement data according to user settings; beyond the control range of the data system will display the message, color-coded or automatically re-measurement.
   Report output functions: the function of sharing data with other systems; the measurement results are saved in Microsoft Word format, Microsoft Excel format, the text file format; personalized settings on the report format; advance preview of the report on the results of the printing .

===================================================
